Professional · Platform MTO
MTOtrigo
The three-seat member of the MTO platform — two passengers, a stretcher or stores for special operations.
The flexible MTO platform
The MTO platform has multiple uses — carrying a single passenger for training or simply for fun, two passengers, stretchers, agricultural equipment… the list seems almost endless. The MTOtrigo is designed for two passengers, giving you independence for unique operations. It is easy to fly and easy to service, with very little infrastructure required.
It is ideal for dropping parachutists or stores, small team insertions, or simply taking two passengers on spectacular scenic tours. The upgraded model now features the Rotax 915 iS or 916 iS, providing superior performance and greater flexibility in your mission set-up.
Stretchers, drops and floats
The MTOtrigo can be fitted with a stretcher and used for medical evacuation or patient transport. An under-seat release mechanism for dropping stores at low altitude and low speed is perfect for resupplying hard-to-reach areas — especially at high altitude.
The MTOtrigo can operate from normal airfields, or be fitted with standard or amphibious floats to become the perfect summer resort aircraft — or a water-based delivery aircraft for up-river support.
Main application areas:
- unique tourist experiences in special areas such as canyons, lakes or the sea,
- medical evacuation or patient transport,
- parachuting,
- carrying and dropping stores,
- fast low-level resupply.
Technical specifications
| Parameter | Value |
|---|---|
| Dimensions: L × W × H (excluding rotor) | 5.25 × 1.9 × 2.8 m (17.2 × 6.2 × 9.2 ft) |
| Rotor diameter | 8.6 m / 8.8 m (28.2 / 28.9 ft) |
| Empty weight | 310 kg (683 lb) |
| MTOM (maximum take-off mass) | 560–650 kg (1,235–1,433 lb) |
| Engine | Rotax 912 ULS / 914 UL / 915 iS / 916 iS |
| Take-off distance | 70–110 m (230–360 ft) ¹ |
| Take-off distance to clear a 15 m obstacle | 250–260 m (820–850 ft) |
| Climb rate | up to 6.0 m/s (1,170 fpm) |
| Max. endurance | up to 4.5 h ² |
| Max. range | up to 550 km (340 mi) ² |
| Cruise speed | 90–185 km/h (55–115 mph) |
| Fuel capacity | 65–96 L (17–25 US gal) |
| Seats | 3 (pilot + 2 passengers) |
| Complies with | BUT (Germany), BCAR Section T (UK), ASRA (Australia), US Primary Category, US Experimental Category, CCAR-21 (China) |
- ¹ Typical aircraft configuration: 1 pilot (80 kg), 40 L fuel, 2,000 ft MSL.
- ² Typical aircraft configuration: 1 pilot (80 kg), full tank, 2,000 ft MSL.
- Requirements for carrying goods or passengers vary by country — consult your aviation authority or contact us.
Pilot Operating Handbook (POH) — MTOsport 2017 (opens the manufacturer's website)
Gallery
Manufacturer's material: AutoGyro GmbH, Hildesheim.
